Martin Audio ADORN A80TW 8″ 2-Way Speaker Inc Bracket 90×50¬∞ 8Œ©/100V White
£415.80£346.50 Incl. VATExcl. VAT
The ADORN A80T is a two-way passive speaker with an elegant design that is perfect for architectural environments that require high fidelity sound from an unobtrusive, compact enclosure. It brings class-leading performance, reliability and value to a wide range of commercial sound applications ‚Äî from retail outlets, bars and restaurants to corporate offices and convention centres.Comprising an 8″ (203mm) LF driver and a 1″ (25mm) polymer dome HF compression driver on a 90¬∞ x 50¬∞ horn, it handles 200W AES, 800W peak and can produce 120dB peak output at 1 metre. It has a smooth frequency response and strong bass reproduction that extends down to 63Hz.With a nominal impedance of 8 ohms, multiple speakers can be driven in parallel from a single channel of a low impedance amplifier, such as the Martin Audio VIA2502 or VIA5002, thereby maximising efficiency and minimising cost. A80T also incorporates a high-quality transformer for 70V/100V line operation, with transformer taps selected by a rotary switch.
- Contemporary, unobtrusive design
- High output capability
- High fidelity sound
- 70V/100V line transformer
- Low and high-frequency overload protection
- Vertical or horizontal orientation
- 90° x 50° coverage
- IP54 with optional waterproof connector cover
- 5-year warranty
- Type: Compact passive two-way system, front ported bass reflex
- Frequency Response: 63Hz-17kHz ± 3dB, -10dB @ 50Hz
- Drivers
- LF: 8” with 2” high-temp voice coil, ferrite motor system
- HF: 1” with 1” exit polymer dome compression driver
- Rated Power: 200W AES, 800W peak
- Recommended Amplifier: VIA2502 or VIA5004 (or VIA5002 for70V/100V line)
- Sensitivity: 91dB
- Maximum SPL: 120dB peak
- Nominal Impedance: 8 ohms
- Dispersion (-6dB): 90° H x 50° V
- Crossover: 2.3kHz passive (LF and HF auto-resetting fuses)
- Transformer Taps:
- 70V: 60/30/15/7.5W
- 100V: 60/30/15W
- Recommended High-Pass Filter: 40Hz 24dB/oct (8 ohm), 60Hz 24dB/oct (Transformer)
- Enclosure: ABS, UL 94V-0 rated
- Finish: White
- Grille: Perforated steel
- Connectors: Low profile 13A push-lock
- Fittings: 6 x M6 inserts for wall or ceiling brackets
- Dimensions Excl. Bracket (WxHxD): 246mm x 421mm x 233mm (9.69in x 16.56in x 9.18in)
- Weight: 9.08kg (20.02lbs)
- Accessories:
- IP54 rating with optional waterproof connector cover (not included)
- Wall bracket WB6/8 (included)
