Description
Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. Receive state-of-the-art live sound. The EW-D ASA does not supply power to EW-DX
Features
- Digital wireless eliminates noise, interference and static bursts
- UHF transmission greatly enhances range, reliability and scalability
- Mobile App streamlines setup and operation and eliminates complicated menus
- Automated setup creates reliable connections with minimal time and effort
- Up to 2,240 selectable frequencies
- 56 MHz Bandwidth will allow for up to 90 channels
Specs
- Frequency ranges:
- EW-D ASA (Q-R-S):
- 470 – 694 MHz
- EW-D ASA CN/ANZ (Q-R-S):
- 470 – 694 MHz
- EW-D ASA (T-U-V-W):
- 694 – 1075 MHz
- EW-D ASA (X-Y):
- 1350 – 1805 MHz
- Antenna splitter: 2 x 1:4 or 1 x 1:8, active
- Gain:
- in A – out A: 0 ± 1 dB
- in A – out A1 ... A4: 0 ± 1 dB
- in B – out B1 ... B4: 0 ± 1 dB
- IIP3: > 25 dBm
- Impedance: 50 Ω
- Reflection loss: 10 dB (all RF outputs)
- Operating voltage: DC +12 V from NT 12-35 CS power supply unit
- Current consumption: 210 mA
- Total current consumption: max. 3 A (with 4 EW-D EM and connected EW-D AB)
- Supply for antenna boosters at ANT RF in A and ANT RF in B:
- DC 12 V
- 320 mA
- Supply for receivers at A1 to A4:
- DC 12 V
- Typically 350 mA,
- max. 500 mA
- Dimensions: Approx. 212 x 168 x 43 mm
- Weight: Approx. 1100 g
- Operating temperature range: -10 °C - +55 °C (14 °F - 131 °F)
- Storage temperature range: -20 °C - +70 °C (-4 °F - 158 °F)
- Relative humidity: 5 - 95 % (non-condensing)
