Shure GLXD6+ Digital Wireless Dual Band Guitar Pedal Receiver Z4

£283.44£236.20 Incl. VATExcl. VAT

SKU: GLXD6+UK=-Z4 Category:
Description

The GLXD6+ Dual Band Guitar Pedal receiver is engineered in a rugged metal design that can be completely integrated into your pedalboard. Go wireless without compromising your tone or complicating your rig.GLX-D+ Dual Band Digital Wireless offers confidence without complexity. Dual-band operation in 2.4 and 5.8 GHz more than doubles the available bandwidth to avoid interference without audio interruption. The receiver is compatible with a selection of lavalier, headset, and vocal microphones. The included lithium-ion battery offers up to 12 hours of runtime.

Features
  • Dual Band technology provides reliable and consistent performance in 2.4 and 5.8GHz
  • Rugged metal chassis design that can be completely integrated into your pedalboard
  • Compatible with 9V power supply in Pedalboards (minimum current: 400mA)
  • Transmitter battery life monitoring via highly visible LED segment display
  • Included Tuner with adjustable reference pitch (432 ‚Äì 447 Hz)
  • Easy powering from pedal boards
  • Included Tuner with adjustable mode (Strobe / Needle) and selectable reference pitch (432 ‚Äì 447 Hz)
  • ¬º" true bypass input allows you to switch between two instruments (one wired and one wireless guitar/bass) during live performance by toggling the push button on the pedal receiver. Integrated guitar input also enables easy transition from practice to live performance
Specs
  • Power Requirements: 9 V ‚Äì 15 V, 400 mA (efficiency level VI power supply)
  • Antenna Type: Dual-band PIFA
  • Dimensions: 5.4 x 3.7 x 1.89 in. (138 x 95 x 48 mm)
  • Weight: 19.75 oz (560 g)
  • Housing: Aluminium alloy
  • Spurious Rejection: > 35 dB, typical
  • Gain Adjustment Range: -20 to 40 dB in 1 dB steps
  • Audio Input Modes: Tuner or True Bypass
  • Audio Output:
  • Configuration
    • 6.35 mm (1/4") output
    • Impedance balanced
  • Impedance
    • 6.35 mm (1/4") output
    • 100 Œ© (50 Œ©, Unbalanced)
  • Maximum Audio Output Level
    • 6.35 mm (1/4") connector (into 3 kŒ© load)
    • +8.5 dBV
  • Pin Assignments
    • 6.35 mm (1/4") connector
    • Tip=audio, Ring=no audio, Sleeve=ground
  • Receiver Antenna Input:
    • Impedance: 50 Œ©
    • Maximum Input Level: -20 dBm
