Sennheiser AWM CH70 Active Directional Antenna for EW-D / EW-DX 823-1075 MHz
£375.21£312.67 Incl. VATExcl. VAT
Description
AWM Antenna is an active directional antenna for use with Evolution Wireless Digital microphone systems. The AWM antenna is designed to enhance the wireless performance of your Evolution Wireless Digital system and can be installed quickly and easily in any room, on a vertical (wall) or horizontal (ceiling) surfaces. The AWM UHF can be connected to any stationary Evolution Wireless Digital receiver or EW-D ASA antenna splitter.
Features
- Active directional antenna
- Adjustable gain settings for different cable length
- Wall, ceiling or mic stand mounting options
- Power supply either via BNC or DC Jack
- Can be connected to any stationary Evolution Wireless Digital receiver or EW-D ASA antenna splitter
- Frequency Range: 823-1075 MHz
Specs
- Frequency ranges
- UHF I: 470 - 694 MHz
- UHF II: 823 - 1075 MHz
- 1 G8: 1785 - 1805 MHz
- Apex angle (horizontal, -3 dB)
- UHF I: N/A
- UHF II: Approx. 80 °
- 1 G8: Approx. 110 °
- Front-to-back ratio
- UHF I: N/A
- UHF II: Approx. 10 dB
- 1 G8: Approx. 10 dB
- Antenna gain
-
UHF I:
- ‚â• +3.0 dBi (480 MHz)
- ‚â• +3.5 dBi (582 MHz)
- ‚â• +4.5 dBi (694 MHz)
- UHF II: ‚â• +6.0 dBi
- 1 G8: ‚â• +6.0 dBi
-
UHF I:
- Antenna polarization: Linear
- Amplification (signal booster, low noise, band selective, +/-1 dB w/o line break)
- Setting: Max. gain [dB]
- +12 dB: 12
- +6 dB: 6
- 0 dB(1): UHF I, UHF II: -0.5; 1G8: -1.5
- -6 dB: -6
- OIP3 (@ +12 dB): ‚â• 35 dBm
- Max. RF output:
- UHF I/UHF II: approx. +22 dBm
- 1 G8: approx. +18 dBm
- RF connection: BNC female, DC coupled
- Impedance: 50 Ω
- DC connection: 5.5 x 1.6 mm DC jack, centre contact +
- Power supply (via BNC or DC jack): 12 V DC (9 - 18 V DC) / max. 100 mA @ 12 V
- LED signalization:
- ON (white= „+12 dB“; blue= „+6 dB“; green= „0 dB“; orange= „-6 dB“)
- OFF (no or insufficient DC supply)
- Mounting connection for tripod or mic stand: 3/8" internal thread
- Mounting holes standard: VESA 100 x 100
- Colour: Traffic white (RAL: 9016)
- Housing material: Halogen-free flame-retardant PC/ABS
- Dimensions:
- (excl. mounting plate) 180 x 180 x 53 mm (7.08 x 7.08 x 2.08")
- (incl. mounting plate): 180 x 180 x 63 mm (7.08 x 7.08 x 2.48")
- Weight Approx.: 700 g (1.54 Ib.)
- Operating temperature: -10 °C to +55 °C (14 °F to 131 °F)
- Storage temperature: -20 °C to +70 °C (-4 °F to 158 °F)
- Relative air humidity: 5 to 95 %
