Name: Shure KSM137/SL Cardioid Condenser Instrument Microphone
Brand: Shure
SKU: KSM137/SL
Availability: InStock

Shure KSM137/SL Cardioid Condenser Instrument Microphone

£444.57£370.48 Incl. VATExcl. VAT

SKU: KSM137/SL Category: Condenser

Description

The KSM137 is a premium, end-address, condenser microphone with a cardioid polar pattern engineered for highly critical studio recording and live sound productions. Its class A, discrete, transformerless preamplifier provides extremely transparent sound capture, and a three position switchable pad and low-cut filter allows for handling of extremely high sound pressure levels (SPL) and controlled bass response. Versatile, durable, and precise, the KSM137 is an outstanding microphone for both live and studio applications.

Features

Highly consistent cardioid polar pattern
Ultra-thin, 2.5 micron, 24 karat gold-layered, low mass Mylar¬Æ diaphragm for superior transient response
Class A, discrete, transformerless preamplifier for transparency, extremely fast transient response, no crossover distortion, and minimal harmonic and intermodulation distortion
Premium electronic components, including gold-plated internal and external connectors
Subsonic filter eliminates low frequency rumble (less than 17 Hz) caused by mechanical vibration
Switchable 15 dB pad for handling extremely high sound pressure levels (SPLs)
3-position switchable pad (0 dB, 15 dB, and 25 dB) for handling extremely high sound pressure levels (SPLs)
3-position switchable low-frequency filter reduces background noise and counteracts proximity effect

Specs

Cartridge Type: Electret Condenser
Polar Pattern: Cardioid
Frequency Response: 20 to 20,000 Hz
Sensitivity open circuit voltage, @ 1 kHz, typical: ‚Äì37 dBV/Pa[1] (14.1 mV)
Maximum SPL: 1 kHz at 1% THD
- PAD ON:
  - 5000 Œ© load: 170 dB
  - 2500 Œ© load: 164 dB
  - 1000 Œ© load: 159 dB
- PAD OFF:
  - 5000 Œ© load: 145 dB
  - 2500 Œ© load: 139 dB
  - 1000 Œ© load: 134 dB
- Signal-to-Noise Ratio: 80 dB
Self Noise equivalent SPL, A-weighted, typical: 14 dB SPL-A
Common Mode Rejection 10 to 100,000 kHz: ‚â•50 dB
Attenuator Switch: 0 , -15 , -25 dB
Low-Frequency Filter Switch: Flat, ‚Äì6 dB/octave below 115 Hz, or ‚Äì18 dB/octave below 80 Hz
Connector: Three-pin professional audio (XLR), male, balanced
Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Power Requirements:
11‚Äì52 V DC phantom power (IEC-61938)
4.7 mA, maximum
Net Weight: 100 g (3.5 oz.)
