CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White

SKU: CYP035
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 1
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 2
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 3
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 4
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 5
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 6
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 7
CYP CR-KP4-W 8-Button IP Keypad Controller, PoE, White - Image 8
Click to enlarge

    £185.00 inc VAT
    £154.17 ex VAT

    2 in stock

    2 available online
    Delivered by TuesdayOrder by 3pm
    Click & Collect Monday ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    Other colours available
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    White version of CYP’s eight-button network keypad for wall mounting. Each tri-colour LED button can run a macro of IP commands, with 32 macros and 128 commands available, and the internal clock lets events run on a schedule. It is powered over Ethernet from an 802.3af switch or by an optional 5V adaptor.

    8
    Buttons
    32
    Macros
    1-gang
    Wall plate
    802.3af
    PoE
    US-style back boxCYP specify a single-gang US-style back box with a minimum depth of 40mm. Check this against the wall box before installing in the UK.
    Features
    8 buttons with tri-colour LEDs on a 1-gang plate
    32 macros, up to 16 commands each and 128 in total
    Time and date scheduling, single or recurring
    Condition checking within macros
    Clock and schedule backup for up to one month
    Configurable daylight saving time
    Control via keypad, Telnet and Web GUI
    Specifications
    Brand CYP
    Model CR-KP4-W
    Buttons 8, tri-colour LED
    Network 1x RJ45
    Service port USB 2.0 Mini-B
    Macros 32 (128 commands total)
    Control Keypad, Telnet, Web GUI
    Power PoE 802.3af or 5V/2.6A DC (optional)
    Power consumption 1.1W
    Mounting Single-gang US-style back box, min 40mm deep
    Dimensions (WxHxD) 100 x 90 x 40mm
    Colour White
    Weight 160g

    Product Reviews

    No reviews yet — be the first to review this product.

    More Information

    • Available in Black (CR-KP4/B) or White (CR-KP4/W)
    • 1-Gang wall plate design with tri-colour LED buttons
    • 32 macros for controlling user equipment
    • Up to 128 total commands can be stored and used across all macros in the system (up to 16 per macro)
    • Supports time and date macro scheduling (single and recurring)
    • Supports condition checking within macro commands for expanded macro design flexibility
    • Supports one month of backup power for the internal clock and schedule function to protect against blackouts and temporary power loss
    • Supports customisable daylight savings time configuration
    • Can be powered by an Ethernet switch that supports the IEEE 802.3af PoE standard (Optional)
    • Controllable via keypad, Telnet and Web GUI
    • NOTE: These keypads use a single gang US style back box: minimum depth = 40mm

    Manuals & Downloads

    PDFManuals & Instructions: CR-KP4-B_CR-KP4-W_PDF-Manual_RDV2.pdfPDF
    PDFManuals & Instructions: CR-KP4_Datasheet_v1.pdfPDF
