CYP PUV-1210PL-RX HDBaseT Lite Receiver 60m for PUV-1082PL-4K22N

Product code: 186174

£177.00 inc VAT
£147.50 ex VAT

SKU: CYP067

(1 Review)

3 in stock

3 available online

Optional Add-Ons

CYP PUV-1082PL-4K22N 10x10 HDBaseT Lite Matrix, 4K with Audio Matrix

£3,675.00 inc VAT
£3,062.50 ex VAT

Add to basket

About this Product

CYP lists this receiver as a match for the PUV-1082PL-4K22N 10×10 HDBaseT Lite matrix, and it also partners the PUV-1210PL-TX transmitter. It outputs HDMI at the display with two-way IR and RS-232, taking its power over the cable by PoH. 4K runs reach 35m on CAT5e/6 or 60m on CAT6a/7.

60m

4K over CAT6a/7

35m

4K over CAT5e/6

PoH

Cable powered

HDCP 2.2

Compliant

Needs a PoH sourceReceiver only, with no power supply. It is powered by PoH from the CYP PUV-1082PL-4K22N matrix or a PUV-1210PL-TX transmitter. This is HDBaseT Lite, not an AVLC receiver.

Features

Receives HDMI and HD audio over HDBaseT Lite

4K up to 35m over CAT5e/6 or 60m over CAT6a/7

Bi-directional IR and RS-232 pass-through

HDCP 2.2, HDCP repeating, CEC and 3D support

Passes Dolby Atmos, Dolby TrueHD and DTS-HD Master Audio

Specifications

CYP PUV-1210PL-RX HDBaseT Lite Receiver 60m for PUV-1082PL-4K22N specifications
Brand	CYP
Model	PUV-1210PL-RX
Inputs	1x HDBaseT (RJ45), 1x IR in (3.5mm)
Outputs	1x HDMI, 1x IR out (3.5mm), 1x RS-232 (9-pin D-sub)
Max resolution	4K UHD@60Hz 4:2:0
HDCP	HDCP 2.2
Distance (4K)	35m CAT5e/6, 60m CAT6a/7
Power	PoH
Compatible with	PUV-1082PL-4K22N, PUV-1210PL-TX
In the box	Receiver, IR blaster, IR extender, manual
Dimensions (WxHxD)	128 x 25 x 108mm
Weight	200g

Full features

HDCP2.2 Compliant
High-Definition video and audio, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)
Supported resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings
4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 60m via CAT6a/7
Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
Supports HDCP repeating and CEC functions
Supports 3D signals

Inputs: 1 x RJ45 [1 x HDBaseT HDMI & Propriety Data], 1 x 3.5mm Stereo mini-jack [1 x Infra Red Receiver]
Outputs: 1 x HDMI [1 x HDMI Uncompressed AV and Data], 1 x 3.5mm Stereo mini-jack [1 x Infra Red Emitter], 1 x 9pin Dsub [1 x RS-232 Data]
PSU: PoH
Dimensions: 128mm [W] x 25mm [H] x 108mm [D]
Net Weight: 200g
Gross Weight: 400g
Product Stock Category: Core Product
