Rated 4.9 (112 reviews)
Adds a USB-C input alongside HDMI on the IP-7000 transmitter, so a laptop can connect with a single cable and share its picture across the gigabit AV network. Analogue audio, IR, RS-232 and USB for KVM travel with the video, and two RJ45 control button ports are fitted. CYP recommend the IP-CS7 controller for large or matrix systems.
USB-C + HDMI
Inputs
4K60 4:2:0
Max resolution
100m
Per cable run
802.3af
PoE
Power supply not includedRuns on PoE from the network switch. Without PoE, order the 5V/2.6A adaptor (PSU-5V2.6A-L) separately.
Features
USB-C and HDMI inputs with HDCP 2.2
Up to 4K30 4:4:4 or 4K60 4:2:0
Unicast and multicast modes with 0, 180 and 270 degree rotation
Analogue line in and out, HD audio pass-through (LPCM, Dolby Digital, DTS)
USB keyboard, mouse and storage extension
IR and RS-232 bypass
2 RJ45 control button ports
Control via IP-CS7, OSD, Telnet, Web GUI and RS-232
Specifications
| Brand | CYP |
| Model | IP-7000C-TX |
| Inputs | 1x USB-C, 1x HDMI, 1x 3.5mm stereo line in |
| Network | 1x RJ45 Gigabit (PoE) |
| Outputs | 1x 3.5mm stereo line out, 1x IR emitter |
| Control ports | RS-232, IR in (3.5mm), USB, 2x RJ45 control button |
| Max resolution | 4096×2160@60 YUV 4:2:0 (HDMI and USB-C) |
| HDMI / HDCP | HDMI 2.0 / HDCP 2.2 |
| Audio formats | 2ch and 8ch LPCM, standard Bitstream |
| Distance | 100m to switch, 100m between switches |
| Control | IP-CS7, OSD, Telnet, Web GUI, RS-232 |
| Power | PoE or 5V/2.6A (PSU not supplied) |
| Power consumption | 5.5W |
| Dimensions (WxHxD) | 231.5 x 25 x 108mm |
| Weight | 640g |
