CYP RE-EDID-4K22 HDMI EDID Manager 4K60 18Gbps with HDCP Modes

Product code: 185998

£177.00 inc VAT
£147.50 ex VAT

SKU: CYP081

2 in stock

2 available online

About this Product

Sources sometimes pick the wrong resolution or audio format because of what a display reports. The RE-EDID-4K22 sits in the HDMI line and controls that EDID data, with read, write, emulate and bypass modes and eight memory slots for learnt EDIDs. It handles 18Gbps 4K60 4:4:4, and is a regular fix when integrating PCs and commercial displays into AV systems.

18Gbps

4K60 4:4:4

EDID modes

Stored EDID sets

HDCP 2.2

Compliant

Features

Read, Write, Emulate and Bypass EDID modes

Stores 8 learnt EDID sets

HDMI 2.0 input and output, 18Gbps 4K UHD, with optional UHD to 1080p output downscaling

HDCP 1.4 and 2.2 compliant, with Follow In, Follow Out and Apple HDCP modes

48-bit Deep Colour up to 1080p@60Hz

USB port for PC-based EDID management

Works with DVI sources via an adaptor (not supplied)

Specifications

CYP RE-EDID-4K22 HDMI EDID Manager 4K60 18Gbps with HDCP Modes specifications
Brand	CYP
Model	RE-EDID-4K22
Input	1x HDMI
Output	1x HDMI
Control port	USB 3 Type B (service and PC)
HDMI / HDCP	HDMI 2.0, HDCP 1.4 and 2.2
Bandwidth	18Gbps
Max resolution	4096×2160@60Hz 4:4:4 8-bit
EDID modes	Read, Write, Emulate, Bypass
EDID memory	8 learnt sets
In the box	EDID manager, 5V/2.6A DC adaptor, manual
Power supply	5V/2.6A DC
Dimensions (WxHxD)	128 x 25 x 75mm
Weight	280g

Full features

HDMI input and output with 18Gbps (6G) 4K UHD support
HDCP 1.4 and 2.2 compliant
Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)
Supports 48-bit Deep Colour up to 1080p@60Hz
Supports Four different EDID modes : Read / Write / Emulate / Bypass modes
Read Mode : Reads the TV/display’s EDID information
Write Mode : Overwrites the TV/display’s EDID information (TV/display needs to be able to support overwrite function)
8 unique sets of EDID settings may be stored via the learning procedure.
Emulator Mode : Allows the source device to read the selected EDID information from the unit’s default or learnt EDID memory
Bypass Mode : Allows the source device to read the EDID information from the TV/display directly
Supports DVI sources when used with a DVI to HDMI adaptor (not supplied)
Supports CEC functionality

Inputs: 1 x HDMI [1 x HDMI Uncompressed AV and Data], 1 x USB 3 Type B [1 x Service and PC port Power & Data]
Outputs: 1 x HDMI [1 x HDMI Uncompressed AV and Data]
PSU: 5V/2.6A
Dimensions (H x W x D): 25 x 128 x 75mm
Net Weight: 280g
Gross Weight: 620g

Product Reviews

No reviews yet — be the first to review this product.

Manuals & Downloads

Manuals & Instructions: RE-EDID-4K22_PDF-Manual_v1.00.pdfPDF

Manuals & Instructions: RE-EDID-4K22_Datasheet_v1.pdfPDF
