Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO

SKU: XVV2SDI2FIBER-12GM2
-6%
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Theatrixx xVision DUAL 4K SDI to Fibre Converter - 12G-SDI to MultiMode opticalCON DUO
Click to enlarge

    £2,328.00 inc VAT
    £1,940.00 ex VATWas £2,473.50 inc VAT. Save £145.50

    1 available online
    More available from supplier in 1–3 weeks
    FREE delivery by ThursdayOrder by 3pm
    Click & Collect tomorrow ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    5 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    Run two 4K SDI feeds onto multi-mode fibre from a single enclosure. The Theatrixx xVision DUAL 12G-SDI to Fibre MultiMode converter houses two fully independent conversion channels in one B-size box, each accepting 12G-SDI input and outputting via Neutrik opticalCON DUO onto multi-mode fibre. For AV rental companies and broadcast operations running dense 4K infrastructure, the dual format cuts hardware count, reduces rigging time, and simplifies power distribution.

    2x 12G-SDI
    Input · BNC
    2x Fibre MM
    Output · opticalCON DUO
    4K UHD
    Resolution · 12G-SDI
    B-Size
    Form Factor · Dual converter
    Features
    Two independent 12G-SDI to multi-mode fibre conversion paths
    B-size format – two converters, one box, one power connection
    Neutrik opticalCON DUO outputs for professional multi-mode fibre
    Rugged touring enclosure – fully enclosed, no exposed PCBs
    Internal power supply for both channels – zero external power bricks
    Professional locking connectors across all inputs and outputs
    Magnetic mounting system with spring-loaded plunger retention
    Reduces hardware count and rigging time for dense 4K deployments
    Specifications
    Input 2x 12G-SDI
    Output 2x Multi-mode fibre (opticalCON DUO)
    Resolution Up to 4K UHD (12G-SDI)
    Channels 2 independent conversion paths
    Input Connectors 2x BNC (12G-SDI)
    Output Connectors 2x Neutrik opticalCON DUO
    Fibre Type Multi-mode
    Form Factor B-Size Standalone (Dual)
    SKU XVV2SDI2FIBER-12GM2

    Product Reviews

    No reviews yet — be the first to review this product.

    Bought this? It takes a minute.
    Review this product

    Reviews are checked by our team before they appear.

    More Information

    • Integrated power supply with locking PowerCON Connector. Never rely on a cluster of wall-warts again.
    • Built-in convenience AC outlet to power nearby projector, TV, laptop, small video projector… Power bar to power both the converter and device not required anymore.
    • Magnetic stacking system and non-skid rubber pad for table top application. Saves at least 10 gaffer tape rolls a year.
    • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
    • Rugged, Tour-ready and aesthetic enclosure
    • Plug-n-play operation; No dipswitches, buttons or menus to fumble with : It just works.
    • Clear and ample status LED indicators for quick troubleshooting.
    • Easy on-the-field identification with unique colour and alphabetic coding system.
    • SFP-based video transmission for interoperability with standard SDI over fibre devices.
    • Reclocked and amplified SDI loop thru
    • Proudly designed and assembled in Canada.
