Equinox UV Mini Batten 9 Blacklight Bar 9 x 3W UV COB LED 394-410nm (EQLED027)

SKU: EQLED027
Equinox UV Mini Batten 9 Blacklight Bar 9 x 3W UV COB LED 394-410nm (EQLED027)
Equinox UV Mini Batten 9 Blacklight Bar 9 x 3W UV COB LED 394-410nm (EQLED027)
Equinox UV Mini Batten 9 Blacklight Bar 9 x 3W UV COB LED 394-410nm (EQLED027)
Equinox UV Mini Batten 9 Blacklight Bar 9 x 3W UV COB LED 394-410nm (EQLED027)
Click to enlarge

    £27.00 inc VAT
    £22.50 ex VAT

    123 in stock

    Order in 14h 37m 37s for delivery by Thursday
    Click & collect tomorrow ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Equinox UV Mini Batten 9 is the shorter, lower-draw model in the Mini Batten range, using 9 x 3W UV COB LEDs at 394-410nm and drawing just 30W. The tighter 65° beam concentrates UV over a narrower area than the 12-LED version, which suits picking out a specific backdrop panel, bar front or props table rather than washing a whole wall. At 478mm without brackets it packs down small for mobile work and home parties.

    LED COUNT
    9 x 3W
    UV COB LED

    WAVELENGTH
    394-410nm
    Ultra violet

    BEAM ANGLE
    65°
    Focused spread

    POWER DRAW
    30W
    100-240V

    Features
    ✓9 x 3W UV COB LED source
    ✓65° beam angle for a more concentrated UV pool
    ✓394-410nm ultra violet wavelength
    ✓Low 30W draw, easy on a shared 13A supply
    ✓Compact 478mm body without brackets fitted
    ✓Bracket allows rigging or floor standing use
    ✓Convection cooled, silent in operation
    ✓Captive power connection

    Note

    Switched operation with a captive power lead – no DMX control on this model. The stated dimensions differ with and without brackets: 512mm long with brackets fitted, 478mm without.

    Specifications
    LED source 9 x 3W UV COB LED
    Wavelength 394-410nm
    Beam angle 65°
    Cooling Convection
    Power connection Captive lead
    Power consumption 30W
    Power supply 100-240V, 50/60Hz
    Fuse F1A 250V
    Dimensions (H x W x D) 98 x 512 x 52mm with brackets; 52 x 478 x 52mm without
    Weight 0.8kg

    More Information

    • 9 x 3W UV COB LED
    • Beam angle: 65°
    • Ultra violet wavelength: 394-410nm
    • Bracket allows for multiple rigging or floor standing applications
    • Captive power connection
    • Convection cooled

    Manuals & Downloads

    PDFManuals & Instructions: EQLED027_ManualPDF
    PDFManuals & Instructions: EQLED027_CE_CertificationPDF
