CYP OR-32SDMI 3x2 Matrix with HDMI, USB-C and SDM Slot, 4K60

Product code: 185701

£519.00 inc VAT
£432.50 ex VAT

SKU: CYP077

2 in stock

2 available online

Optional Add-Ons

CYP SDM-WPS-HP Hyshare Pro Wireless Presentation Module for SDM Slot

£553.00 inc VAT
£460.83 ex VAT

Add to basket

About this Product

A modular take on CYP’s 3×2 meeting room matrix: the inputs are one HDMI, one USB-C and a slot for an SDM input card, switched to two HDMI outputs at up to 4K60 4:4:4. Fitting the SDM-WPS-HP card adds Hyshare Pro wireless presentation to the same unit. A USB 3.0 hub with two host and two device ports, gigabit Ethernet and control by Web GUI, Telnet or RS-232 round it off.

3×2

Matrix

4K60 4:4:4

Max resolution

SDM module slot

USB 3.0

Hub

SDM module is a separate productThe third input is an SDM card slot. Modules such as the SDM-WPS-HP wireless presentation card are separate products and need ordering alongside.

Features

HDMI, USB-C and SDM slot inputs to 2 HDMI outputs

4K60 4:4:4 with HDR10, HLG and Dolby Vision, HDCP 2.2

One slot for CYP SDM series input cards

USB 3.0 hub: USB-B and USB-C host ports, 2 USB-A device ports

Gigabit Ethernet

8ch LPCM, Bitstream and HD Bitstream pass-through

Event automation via RS-232, IP or CEC

Specifications

CYP OR-32SDMI 3×2 Matrix with HDMI, USB-C and SDM Slot, 4K60 specifications
Brand	CYP
Model	OR-32SDMI
Inputs	1x HDMI, 1x USB-C, 1x SDM module slot
Outputs	2x HDMI, 1x 3.5mm stereo
USB	1x USB Type-B host, 1x USB-C host, 2x USB Type-A
Network	1x RJ45
Max resolution	4096×2160@60 4:4:4
HDMI / HDCP	HDMI 2.0 / HDCP 2.2
Audio formats	LPCM 2.0/5.1/7.1, HD Bitstream
Control	Web GUI, Telnet, RS-232 (3-pin Phoenix)
Power	24V/5A
Power consumption	75W (with USB-C PD)
Dimensions (WxHxD)	231.5 x 25 x 158mm
Weight	940g

Full features

3 x 2 HDMI output matrix with USB-C, HDMI and SDM module slot inputs
One input module card slot for CYP SDM series module cards. Look for SDM- product codes
Supports USB 3.0 with one USB-B port, one USB-C port for connecting to a host PC, and two USB-A ports for peripheral devices and storage extension.
Supports gigabit Ethernet
Supports pass-through of 8 channel LPCM, bitstream & HD bitstream audio formats.
Supports 4K HDR formats by HDR10, HLG and Dolby Vision
Supports basic signal event automation (via RS-232, IP or CEC)

Inputs: 1 x HDMI [1 x HDMI Uncompressed AV and Data], 1 x USB-C [1 x USB-C USB-C / Thunderbolt], 1 x SDM input module slot [1 x Multi use SDM input module slot], 1 x Phoenix (3-pin) [1 x RS-232], 1 x USB Type B [1 x USB Propriety Data], 1 x RJ45 [1 x IP Control]
Outputs: 2 x HDMI [2 x HDMI Uncompressed AV and Data], 1 x 3.5mm Stereo mini-jack [1 x Analogue Stereo (L/R)], 2 x USB Type A [2 x USB Propriety Data]
PSU: 24V/5A
Dimensions (H x W x D): 25 x 231.5 x 158mm
Net Weight: 940g
Gross Weight: 2.26kg

Product Reviews

No reviews yet — be the first to review this product.

Manuals & Downloads

Manuals & Instructions: OR-32SDMI_PDF-Manual_V1.01.pdfPDF

Manuals & Instructions: OR-32SDMI_Datasheet.pdfPDF
