CYP SY-XTREAM-C HDMI to USB-C Capture, 4K30 with 4K60 Bypass

SKU: CYP043
CYP SY-XTREAM-C HDMI to USB-C Capture, 4K30 with 4K60 Bypass - Image 1
CYP SY-XTREAM-C HDMI to USB-C Capture, 4K30 with 4K60 Bypass - Image 2
CYP SY-XTREAM-C HDMI to USB-C Capture, 4K30 with 4K60 Bypass - Image 3
CYP SY-XTREAM-C HDMI to USB-C Capture, 4K30 with 4K60 Bypass - Image 4
Click to enlarge

    £266.00 inc VAT
    £221.67 ex VAT

    1 in stock

    1 available online
    FREE delivery by TuesdayOrder by 3pm
    Click & Collect Monday ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The USB-C member of CYP’s capture range records HDMI at up to 4K30 uncompressed over a USB 3.0 link, with a 4K60 HDR loop out for a monitor. As well as HDMI audio, a second audio stream can be taken from the line input, the mic input, or both mixed. It is bus powered from the USB-C port; CYP point users with USB-A only computers to the SY-XTREAM.

    4K30
    USB capture
    4K60 HDR
    HDMI bypass
    USB-C
    Connection
    Line + mic
    Audio inputs
    HDCP capture and software limitsCapture of HDCP-encrypted sources is not supported. Settings beyond basic capture need CYP’s control software, which runs on Windows 10 or later only.
    Features
    Uncompressed capture up to 4K30 over USB 3.0 (USB-C)
    HDMI bypass output up to 4K60 with HDR
    Sources above 30Hz at 4K are converted to 4K30 for capture
    3.5mm line and mic inputs with built-in mixer
    HDMI audio plus a separate analogue audio stream
    UVC/UAC compliant, supports OBS on Windows, macOS and Linux
    Bus powered, no external PSU
    Specifications
    Brand CYP
    Model SY-XTREAM-C
    Inputs 1x HDMI, 1x 3.5mm stereo line, 1x 3.5mm mic
    Outputs 1x HDMI bypass, 1x USB-C
    USB capture Up to 4K30 4:4:4, LPCM 2.0
    Bypass resolution 4K60 4:4:4 with HDR
    HDMI / HDCP HDMI 2.0 / HDCP 2.2 bypass
    Line in 1 Vrms
    Power USB-C bus powered
    Power consumption 4.13W
    Dimensions (WxHxD) 84 x 23 x 113mm
    Weight 180g

    Product Reviews

    No reviews yet — be the first to review this product.

    More Information

    • HDMI input and output supports up to 4K@60Hz with HDR bypass
    • HDCP 2.2 and HDCP 1.x compliant Note: Video capture of sources using HDCP encryption is not supported
    • USB 3.0 connection allows uncompressed video and audio data capture (up to 4K@30Hz, LPCM 2.0) Note: 4K sources with framerates higher than 30Hz are automatically converted to 4K@30Hz for USB capture
    • 2 additional analog audio inputs via 3.5mm ports (1 x Stereo & 1 x Microphone)
    • Supports capture of stereo audio from the HDMI input (LPCM 2.0) as a part of the primary stream, as well as audio from one or both of the analog audio inputs as a secondary audio stream
    • Integrated audio mixer provides a way to combine the line and mic analog audio inputs
    • Complies with the UAC (USB Audio Class) and UVC (USB Video Class) standards, allowing the unit to support most common capture and video streaming software Note: Access to many of the software controllable features of the unit, beyond simple video capture, requires the use of the USB Video Capture Control software which is only available for Windows 10 or later PCs
    • Supports video timing stabilization to help ensure a reliable and stable USB capture stream
    • Unit may be powered directly via USB-C connection (USB3.0)
    • Supports the Free OBS (Open Broadcaster Software) streaming software which is available for Windows 10 (or later), macOS, and Linux

    Manuals & Downloads

    PDFManuals & Instructions: SY-XTREAM-C_PDF-Manual_RDV1.pdfPDF
    PDFManuals & Instructions: SY-XTREAM-C-Datasheet_v1.pdfPDF
