Biamp Apart D-ALINP Active Local Input Panel Decora Style Mic/Line White

SKU: 910-00670
Apart D-ALINP Active Local Input Panel Decora Sytle Mic/Line White
Click to enlarge

    £158.00 inc VAT
    £131.67 ex VAT

    3 available online
    More available from supplier in 1–3 weeks
    Delivered by MondayOrder by 3pm
    Click & Collect tomorrow ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Apart D-ALINP (910-00670) is an active local input panel in a Decora style white finish, providing a balanced microphone input and an unbalanced line input. Both inputs have individual volume controls and are automatically mixed before the pre-amp, with a built-in mic pre-amplifier and line transformer. It connects via 3-pole euroblock and is phantom powered.

    Key Features
    Decora style wall panel, white
    Balanced mic and unbalanced line inputs
    Individual volume control per input
    Built-in mic pre-amplifier
    Built-in line transformer
    Inputs automatically mixed before the pre-amp
    3-pole euroblock connector
    Phantom powered
    Cable runs up to 600 m
    Specifications
    Type Active local input panel
    Inputs Balanced mic and unbalanced line
    Output level 1V balanced, 0 dB
    Frequency range Mic 150 Hz – 20 kHz, Line 50 Hz – 20 kHz
    Input impedance Mic 4k, Line 8.5k ohms
    Sensitivity Line 370 mV, Mic 16 mV
    Signal to noise Greater than 86 dB
    THD Less than 0.05%
    Connector Euroblock 3-pole
    Power Phantom, less than 0.1 W
    Max cable length 600 m
    Height 115 mm
    Width 116 mm
    Depth 38 mm
    Weight 0.21 kg

    Product Reviews

    No reviews yet — be the first to review this product.

    Bought this? It takes a minute.
    Review this product

    Reviews are checked by our team before they appear.

    More Information

    • Easy to use and ultra-convenient
    • Balanced mic and unbalanced line inputs
    • Individual volume adjustment control for each input
    • Built-in mic pre-amplifier
    • Built-in high quality line transformer
    • Line and mic inputs automatically mixed before the pre-amp / mixing amp

    Manuals & Downloads

    PDFDatasheetPDF
    PDFUser GuidePDF
