The Apart KUBO3 (930-00683-00002) is a compact cube-design surface-mount loudspeaker with a 3″ full-range driver and bass reflex port, rated 25W continuous (100W peak) at 8 Ohms. It is supplied in white with a K-Mount bracket and K-bolts, allows 140 degree vertical or horizontal positioning, and multiple units can be daisy chained. Zoom Certified and IP40 rated.
Key Features
3″ full-range driver with bass reflex port
25W continuous, 40W dynamic at 8 Ohms
K-Mount bracket and K-bolts included
140 degree vertical or horizontal mounting
Daisy chaining of multiple KUBO units
Magnetic end caps conceal connections and hardware
Loudspeaker overload protection for 24/7 operation
Zoom Certified, IP40 rated
Specifications
| System | Full-Range |
| Operating Mode | Passive |
| Transducers | 1 x 76 mm polypropylene cone |
| Power | 25W continuous @ 8Ω; 100W peak |
| Frequency range | Operating Range (-10dB): 115 Hz to 20 kHz |
| Sensitivity | Nominal Sensitivity @ 1m: @ 1W, 84 dB @ 2.83V, 84 dB |
| SPL | Nominal Maximum SPL @ 1m: Peak, 104 dB Continuous, 98 dB |
| Beamwidth | Nominal Beamwidth (H x V): 100° x 100° |
| Recommended amplifier | 25W to 50W @ 8Ω (14V to 20V) |
| Input Type | Input Connection: 2 x 2-way Euroblock connectors for daisy-chaining; connectors accept up to 12 AWG (2.5 mm²)conductors |
| IP rating | IP40 per IEC 60529 |
| Operating Environment | Indoor |
| Mounting | Mounting Provisions: U-bracket |
| Included Accessories | Included Accessories: U-bracket; safety cable; Optional Accessories: LRABAS(-BL/-W): Basic light rail adaptor, black or white, LRAPRE(-BL/-W): Premium light rail adaptor, black or white |
| Dimensions | 125 x 131 x 109 mm (H x W x D) |
| Weight | 1 kg |
