The Ecler AMBIT 18 is a 2-way surface mount speaker with an 8 inch woofer and 1.18 inch dome tweeter, and this listing is for a pair in white. Each speaker has a built-in transformer with 100V taps up to 60W and an 8 ohm position rated at 100W RMS, in an IP54, UV resistant cabinet. It is used for music and voice in larger bars, restaurants, gyms, halls, shops and covered outdoor areas.
8in + 1.18in
2-way
IP54
Indoor and outdoor
60W
Max 100V tap
100W
RMS at 8 ohms
Features
Supplied as a pair
2-way design: 8 inch woofer with 1.18 inch dome tweeter, 2 kHz crossover
100V taps at 60W, 30W, 15W and 7.5W; 70V taps at 30W, 15W, 7.5W and 3.75W
8 ohm position, 100W RMS
IP54 rated ABS cabinet with aluminium grille and anti-UV treatment to limit colour fade
Spring-loaded input terminals with waterproof rubber cover
Wall mount hardware, safety sling, screws and wrench included
White finish (RAL 9016)
Specifications
| Frequency range | 75 Hz to 20 kHz (-10 dB) |
| Coverage | 125° x 120° (H x V) |
| Power handling | 100W RMS, 400W peak (8 ohms) |
| Sensitivity | 90 dB (1W/1m) |
| Maximum SPL | 110 dB continuous, 116 dB peak |
| 100V taps | 60W, 30W, 15W, 7.5W, 8 ohms |
| 70V taps | 30W, 15W, 7.5W, 3.75W, 8 ohms |
| Recommended amplifier | 200W RMS (8 ohm use) |
| Drivers | 8 in woofer, 1.18 in dome tweeter |
| Crossover | 2 kHz |
| Connection | Spring-loaded terminals |
| Environmental | IP54 |
| Materials | ABS cabinet, aluminium grille |
| Dimensions (W x H x D) | 258 x 258 x 225 mm |
| Weight | 5.6 kg |
| Operating temperature | -20°C to 70°C |
| Colour | White (RAL 9016) |
| Quantity | 2 speakers |
