8-way DMX splitter, booster and merger with two inputs, passthroughs and eight outputs electronically opto-isolated from each other and from the inputs. Each output toggles between the A and B input with indicator LEDs, and every input and output supports the RDM protocol, so the rig keeps bidirectional fixture communication rather than losing it at the splitter, which is the usual casualty of a cheap one.
8
Outputs
2
Inputs
RDM
Supported
1U
Format
Features
8 opto-isolated outputs
2 inputs with passthroughs
Full RDM protocol support on all inputs and outputs
Per-output A/B routing with indicator LEDs
Splitter, booster and merger in one unit
Simplifies cabling. Lets a rig be wired in a star rather than daisy-chained
Independent driver on every output
Seetronic XLR connectors
Rugged 1U 19″ rack chassis with an M10 mounting point for clamps
Specifications
| Brand | Elumen8 |
| Series | Cygnus |
| Manufacturer part number | ELUM252 |
| Type | DMX / RDM splitter, booster and merger |
| Inputs | 2, with passthrough |
| Outputs | 8 |
| RDM | Supported on all inputs and outputs |
| Isolation | Opto-isolated |
| Routing | Per-output A/B toggle with indicator LEDs |
| Connectors | 5-pin XLR, Seetronic |
| Format | 1U 19″ rack, M10 clamp point |
