High-output IP65 pixel batten for the most demanding environments. 18 x 25W RGBL quad-colour LEDs deliver an intense 6° beam, with optional 20°, 45° and 60° lenses available where a broader wash is wanted. Full pixel mapping over DMX, Art-Net or sACN, with refresh rates selectable to 24kHz for camera. Fully rotatable 4-position brackets handle floor-standing or truss rigging, and a tool-free link system joins units side by side or stacks them vertically into grid arrays.
18 x 25W
LEDs
IP65
Rated
6°
Beam
24kHz
Refresh
IP65, weather resistant, not weatherproof foreverAn IP65 housing survives rain, dust and sand on a festival site. It is not a licence to leave a fixture outdoors unattended for a season: check the gland seals and connector caps at every get-in, and never power up a fixture with an open, unsealed connector.
Features
18 x 25W RGBL quad-colour LEDs
Intense 6° beam as standard
Optional 20°, 45° and 60° lenses
Full pixel mapping
DMX, Art-Net and sACN protocols
Refresh rate selectable to 24kHz
Fully rotatable 4-position mounting brackets
Tool-free link system, linear or grid arrays
Convection cooling and rugged IP-rated connectors
Specifications
| Brand | Elumen8 |
| Manufacturer part number | ELUM721 |
| Type | IP pixel batten |
| LEDs | 18 x 25W RGBL quad-colour |
| Ingress protection | IP65 |
| Beam angle | 6° (optional 20°, 45°, 60° lenses) |
| Protocols | DMX, Art-Net, sACN |
| Refresh rate | Selectable to 24kHz |
| Rigging | 4-position rotatable brackets, quick-release omega clamps |
| Linking | Tool-free, side-by-side or stacked |
| Cooling | Convection |
| Power consumption | 400–800W |
