Biamp Apart CM20DTS 4.25" Thin Edge Shallow Enclosed Ceiling Speaker 16Ω 100V

Product code: 154432

£115.00 inc VAT
£95.83 ex VAT

SKU: 910-00631
41 available online
More available from supplier in 1–3 weeks
Delivered by WednesdayOrder by 3pm tomorrow
Click & Collect Tuesday ›Collect from us in Wembley
VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
1 Year Manufacturer Warranty Included

About this Product

Connection: 100V line (taps 20 / 10 / 5 / 2.5W) or low impedance (16Ω).

Apart CM20DTS install ceiling speaker, 4.25″ thin edge shallow driver, designed for distributed audio in commercial spaces. 20W 100V line operation with multiple power tappings, plus low-impedance alternate.

CM20DTS
Model · 4.25″ thin edge shallow
20W
Power · 100V
4.25″ thin edge shallow
Driver
Quick fix
Install · Apart system

Features

4.25″ two-way
Shallow depth for low ceiling voids
Thin-edge grille
100V or 16Ω
Compatible with standard 100V install amps
Paintable / discreet finishes

Specifications

Biamp Apart CM20DTS 4.25″ Thin Edge Shallow Enclosed Ceiling Speaker 16Ω 100V specifications
SKU 910-00631
Type Two-way 4.25-inch ceiling loudspeaker
Drivers LF 1 x 4.25 inches; HF 1 x 1 inch
Power 40W continuous; 160W peak
Transformer 70V: 20W, 10W, 5W, 2.5W, 1.25W; 100V: 20W, 10W, 5W, 2.5W
Impedance Nominal Impedance:; 16Ω
Frequency range 90 Hz to 22 kHz
Sensitivity Sensitivity (1W/1m) 87 dB
Maximum Output Max Output @1m: 103 dB; 109 dB peak
Dispersion 150° H x 100° V
Operating Environment Indoor
Finish White RAL 9010
Weight 2.0 kg
Certifications UL1480A, UL2043,; CSA C22.2#62368-1

Full features

  • APART CM20DTS Ceiling speaker
  • Produces a dynamic and warm sound
  • Ideal for high-quality background music and voice reproduction
  • Suitable for any kind of ceiling structure
  • Rotatable 70/100 volt power tapping selector
  • Offers 16 ohms connectivity

Full specifications

General

  • Loudspeaker system: 2-way
  • Woofer size: 4.25 inch
  • Woofer cone material: coated paper
  • Tweeter size: 1 inch
  • Mounting system: 2 screws
  • 100V transformer power taps: 20 - 10 - 5 - 2.5 watts
  • 70V transformer power taps: 20 - 10 - 5 - 2.5 - 1.25 watts
  • Impedance: 16 ohms
  • Low impedance dynamic power: 60 watts
  • Low impedance RMS power: 40 watts
  • SPL 1W/1m: 87 dB
  • Max SPL 1m: 103 dB (109 dB peak)
  • Frequency response: 90 - 22K Hz
  • Main construction material: ABS plastic

Physical & Dimensions

  • Outside diameter: 223mm
  • Depth: 84mm
  • Cutout: 193mm
  • Installation grip range: 3 - 41mm
  • Weight: 2.05kg
