Biamp Apart SDQ5PIR White 5" Active Speaker+Slave+RS232+IR Remote

SKU: 911.1477.900
Apart SDQ5PIR White 5″ Active Speaker+Slave+RS232+IR Remote
Click to enlarge

    £142.00 inc VAT
    £118.33 ex VAT

    51 available online
    More available from supplier in 1–3 weeks
    Delivered by MondayOrder by 3pm tomorrow
    Click & Collect Friday ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp
    Optional Add-Ons
    Apart ACPL Wired Remote Line/Mic Input Wall Plate for SDQ5PIR Biamp Apart ACPL Wired Remote Line/Mic Input Wall Plate for SDQ5PIR
    £70.00 inc VAT
    £58.33 ex VAT
    Add to basket
    Apart ACPR Wired Remote Line Input Wall Plate for SDQ5PIR Biamp Apart ACPR Wired Remote Line Input Wall Plate for SDQ5PIR
    £70.00 inc VAT
    £58.33 ex VAT
    Add to basket

    About this Product

    The Apart SDQ5PIR (SKU 911.1477.900) is an active 2-way bass-reflex speaker in white with a 5.25 inch woofer and 1 inch tweeter, rated 2 x 30W RMS. Supplied as a master with passive slave, it accepts two stereo inputs and is controllable by the included IR remote or RS232, suited to monitor and AV/multimedia use.

    Key Features
    Active 2-way bass-reflex system
    5.25 inch woofer and 1 inch tweeter
    2 x 30W RMS output power
    Master unit plus passive slave
    Two stereo inputs (A/B), mixable or selectable
    3.5 mm mini-jack and balanced inputs
    IR remote control included
    RS232 control for system integration
    RJ45 connector for optional wall panel
    Multifunction LED status indicator
    Magnetically shielded
    Mounting brackets and power cord included
    Specifications
    System Active 2-way bass-reflex
    Woofer 5.25 inch, polypropylene
    Tweeter 1 inch
    Output power 2 x 30W RMS
    Power supply 230 VAC
    Sensitivity (1W/1m) 86 dB
    Max SPL (1m) 101 dB
    Frequency response 45 Hz – 20 kHz
    Control IR remote, RS232, optional wall panel
    Mounting U-bracket
    IP rating IP40
    Dimensions (W x H x D) 180 x 253 x 162 mm
    Weight 5.6 kg

    Product Reviews

    No reviews yet — be the first to review this product.

    Bought this? It takes a minute.
    Review this product

    Reviews are checked by our team before they appear.

    More Information

    • Active 2 way bass-reflex speaker system
    • Ideal for monitor, Audio-Video applications, multimedia applications
    • Powerfull HiFi 5.25” woofer and 1” tweeter
    • Mounting brackets, IR remote control and power cord included
    • 2 x 30 watts RMS output power, 200 Watts PMPO dynamic
    • Enhanced bass response by DTB reflex tuning
    • Multifunction led indicator: standby (orange), on (green), overload (red), off (led not lit)
    • Hi-Q balanced inputs
    • Stereo inputs on standard 3.2 mm mini stereo jack, compatible with headphone outputs and line inputs (Computer, MP3 players)
    • Input sources A, B or via optional wall panel
    • Inputs A and B can be mixed together or selected individually by infrared remote control or RS232
    • Magnetically shielded
    • Stylish design, suited for placement in corners
    • Very high efficiency, high output
    • Standby mode for low power consumption
    • Controllable via infrared remote (included), RS232, wall panels (optional)
    • RS232 control for increased integration in automated audio systems using standard 9 pin serial cable.
    • RJ45 remote wall panel connector (not compatible with computer networks or other types of remote control cabling)

    Manuals & Downloads

    PDFUser GuidePDF
    PDFDrawing: SDQ5PIRPDF
