Equinox Fusion Reflecta Moving Head Mirror Effect

Name: Equinox Fusion Reflecta Moving Head Mirror Effect
Brand: Equinox
SKU: EQLED079
Price: 294.00 GBP
Availability: InStock

SKU: EQLED079

£294.00 inc VAT
£245.00 ex VAT

9 in stock (more available subject to additional lead time)

About this Product

The Equinox Fusion Reflecta is a multi-function moving head built around a 178mm flat reflective mirror that flips 180° via DMX to reveal a half mirror ball on the reverse side. Surrounding the mirror is a ring of 50 tri-colour LEDs, turning the fixture into a single rigging point that can reflect external beams, throw classic mirror-ball shards across a room, or run as a self-contained colour effect.

FLAT MIRROR

178mm

Diameter

FLIP

180°

DMX-controlled

LED RING

50 LEDs

Tri-colour

TILT

360°

Continuous

Features

✓
178mm flat reflective mirror redirects external beams

✓
Half mirror ball on the reverse side for classic shard effects

✓
180° flip switches between mirror and ball via DMX

✓
Continuous 360° tilt with variable rotation speed

✓
50 tri-colour LEDs in a ring around the mirror face

✓
Pairs with any external beam fixture for amplified effects

✓
Single rigging point for three combined effect types

✓
DMX-controlled for full integration into existing rigs

Note

The Reflecta has no internal beam source. To use the mirror-ball mode you must aim a separate fixture (LED beam, pinspot, etc.) at the ball — the brighter the source, the more visible the room shards.

Specifications

Brand	Equinox
Model	Fusion Reflecta
Order code	EQLED079
Fixture type	Moving head mirror / mirror-ball effect
Flat mirror diameter	178mm
Reverse face	Half mirror ball
Flip	180° via DMX
Tilt	Continuous 360°, variable speed
LED ring	50 tri-colour LEDs

More Information

1 x Half mirror ball (200mmØ)
1 x Flat mirror (178mmØ)
Highly reflective mirrors with 99% reflection
50 x tri-colour 5050 SMD LEDs (RGB)
DMX channels: 3/5/8/13/16/85 or 88 selectable
Manual mode
Pan/tilt auto correction
16-Bit pan/tilt positioning
Pan: 540°, Tilt: 360° continuous
360° continuous mirror ball rotation in both directions
Quick release omega clamps included
Square hole spacing on omega clamp receivers allows for clamps to be mounted in all orientations
4 button menu with 2.6” LCD display
PowerTwist TR1 input/output
3-Pin XLR input/output
5-Pin XLR input/output
Convection cooled

Manuals & Downloads

Manuals & Instructions: EQLED079_ManualPDF

Manuals & Instructions: EQLED079_CE_CertificationPDF
