Neumann MCM 114 Stereo Set Miniature Clip Mic System for Piano

Product code: 98509

£1,196.00 inc VAT
£996.67 ex VAT

SKU: 008712
Ordered from supplier, allow 1–3 weeks
FREE delivery by Tue 15th DecOrder by 3pm tomorrow
Click & Collect Mon 14th Dec ›Collect from us in Wembley
VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
1 Year Manufacturer Warranty Included

About this Product

The Neumann MCM 114 Stereo Set for Piano is a complete two-channel miniature clip-mic system built around two KK 14 cardioid electret capsules, supplied with magnetic holders for upright and grand piano applications. Designed for live reinforcement and broadcast capture, it gives engineers a stable, repeatable Neumann-grade stereo image without lid bars, gooseneck stands or visible mic positioning on stage.

2 x KK 14
CAPSULES · stereo pair, cardioid
153 dB
MAX SPL · handles loud transients
Magnetic holders
MOUNT · piano / grand piano
45°
GOOSENECK LOCK · indexed rotation
Stereo setUnlike the single-channel MCM 114 sets, this configuration ships as a stereo pair so a single SKU covers both channels of a piano rig. Magnetic mounts allow rapid placement and re-placement during turnarounds without taping or re-adjusting brackets.

Features

Stereo pair of KK 14 cardioid capsules
153 dB max SPL handles fortissimo concert grand performance
Magnetic holders, quick to place, repeatable across shows
Suitable for upright and grand pianos
Gooseneck holders rotate and lock in 45° increments
Visually discreet, no boom stands cluttering the stage
Modular construction, serviceable rather than disposable
Compatible with the wider MCM clip range for instrument changes
NoteThis is the stereo MCM 114 set, two complete mics with magnetic piano holders. For other instruments use the relevant single-channel MCM 114 set.

Specifications

Neumann MCM 114 Stereo Set Miniature Clip Mic System for Piano specifications
SKU 008712
Capsules 2 x KK 14, cardioid electret (stereo pair)
Maximum SPL 153 dB
Mounting Magnetic holders for upright and grand piano
Gooseneck adjustment Rotates and locks in 45° increments
Construction Modular, capsules, goosenecks and holders individually replaceable

Full features

  • Elevates electret principle to Neumann sound standards
  • Durability increases ROI up to tenfold
  • A single capsule for loud and soft instruments
  • Works with key transmitter bodypacks
  • Stereo System for Piano
  • Includes mounting accessories, mic, cable and case

Full specifications

MCM 114 (KK 14 with MCM 100) Specifications

  • Acoustic operating principle: Pressure gradient transducer
  • Directional pattern: Cardioid
  • Frequency range: 20 Hz - 20 kHz
  • Sensitivity at 1 kHz into 1 kΩ: 3.6 mV/Pa 49 dBv ± 2 dB
  • Rated output impedance: KK 14: 10 Ω | MCM 100: 50 Ω
  • Rated load impedance: 1000 Ω
  • Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL): 63 dB
  • Signal-to-noise ratio, A-weighted1) (rel. 94 dB SPL): 71 dB
  • Equivalent noise level, CCIR1): 31 dB
  • Equivalent noise level, A-weighted1): 23 dB-A
  • Maximum SPL2) for THD < 0.5 %:
    • with MCM 100, Usupply = 10 V, Rfeed = 20 kΩ: 153 dB SPL
    • with Usupply = 5 V, Rfeed = 8.25 kΩ: 147 dB SPL
  • Dynamic range of the amplifier, A-weighted2) for THD < 0.5 %: 130 dB
  • Power supply: KK 14: ≤ 10 V, with Rfeed = 20 kΩ | MCM 100: 48 V ± 4 V (P48, IEC 61938)
  • Current consumption: KK 14: 0.22 mA | MCM 100: 3.5 mA
  • Required connector: XLR-3F
  • Weight: KK 14: 2.3 g | MCM 100: 96 g
  • Dimensions (Ø x L): KK 14: Ø 12 mm x 12 mm | MCM 100: Ø 22 mm x 77 mm
  • Operating temperature range: 0 °C - +40 °C (32 °F - 104 °F)
  • Storage temperature range: −20 °C - +70 °C (−4 °F - 158 °F)
  • Operating humidity range: 0 % - 90 %
  • Storage humidity range: 0 % - 95 %
