Allen & Heath dLive CTi1500 12 Fader Surface

Product code: 204

Enquire for price

SKU: DLIVE-CTI15/240x
1 available online
FREE delivery by WednesdayOrder by 3pm tomorrow
Click & Collect Tuesday ›Collect from us in Wembley
VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
3 Year Manufacturer Warranty Included

About this Product

The dLive CTi1500 is the ultra-portable entry point to the dLive C Class surface range. With 12 faders across 6 layers, a 12″ capacitive touchscreen, and built-in audio I/O including mic/line inputs and AES3 digital connectivity, it delivers the full dLive mixing experience in the smallest possible footprint, ideal for fly dates, remote broadcast positions, and compact installed systems.

12
Faders · 72 strips across 6 layers
12″
Touchscreen · Capacitive multitouch
19
SoftKeys · Fully assignable
6 in / 6 out
Local I/O · Mic/line in, line out
System ArchitectureThe CTi1500 connects to any dLive MixRack via gigaACE with a DX link for I/O expansion. Built-in I/O includes 6 mic/line inputs, 6 line outputs, 1 stereo AES3 input and 1 stereo AES3 output, a 128-channel 96 kHz I/O port, 2 network ports, Wordclock BNC I/O, and a video output. The integrated PSU and ultra-compact form factor make it the most portable dLive surface option.

Features

Ultra-portable design, the lightest dLive surface
12″ capacitive touchscreen with Harmony UI
6 mic/line inputs and 6 line outputs built in
AES3 stereo digital input and output
128-channel 96 kHz I/O port for option cards
Fully customisable fader layout across all 6 layers
gigaACE and DX link connections
Integrated power supply
NoteThe CTi1500 shares the same 12-fader layout and I/O complement as the C1500 but in a more travel-friendly chassis. Both surfaces are fully compatible with all dLive MixRacks and share identical mixing capabilities.

Specifications

Allen & Heath dLive CTi1500 12 Fader Surface specifications
Faders 12 motorised (72 strips across 6 layers)
Touchscreen 1 x 12″ capacitive multitouch
Assignable SoftKeys 19
Local Analogue Inputs 6 mic/line
Local Analogue Outputs 6 line
Digital I/O 1 stereo AES3 in / 1 stereo AES3 out
I/O Port 128 channel, 96 kHz
MixRack Connection gigaACE
Power Supply Integrated
SKU DLIVE-CTI15/240x

Full features

dLive CTi1500 Features

Ultra-Portable Design

  • Weighs just 11.5 kg (25.4 lbs)
  • Fly-ready: sub-23 kg with flightcase*, I/O card & dust cover
  • Built with titanium side panels and lightweight alloy metalwork
    *Requires flightcase under 10 kg (22 lbs)

Flexible Control Surface

  • 12 motorised faders with a fully assignable layout (up to 72 fader strips)
  • 12" capacitive touchscreen with Harmony UI for seamless control
  • Gesture control - pinch, swipe, drag & drop
  • Wrap-around controls for intuitive mixing
  • Dedicated EQ view with real-time visual feedback
  • Configurable widget areas for Scenes, FX, meters & more
  • 19 assignable SoftKeys
  • Engineer's Wedge and IEM strips for quick monitoring

Comprehensive Metering & Recording

  • Full multi-point metering with daylight visibility
  • USB stereo recording & playback

Professional I/O

  • 6 XLR mic/line inputs, 6 XLR line outputs
  • AES3 digital in/out (1 stereo pair each)
  • GigaACE gigabit link to MixRack
  • DX Link for remote I/O expansion
  • 128x128 channel I/O Port at 96 kHz
  • 2 network ports, BNC Wordclock I/O, and video output
