The Ecler SAMI402 is a 1U analogue installation mixer with 3 mic/line inputs and 1 stereo line input, a stereo or dual mono main output and an AUX/REC output. It has a 3-band tone control, talkover priority for the microphones and a mute input for fire alarm interfacing. It is used in bars, cafés, shops, gyms, small function rooms and schools.
4
Inputs
3
Mic/line
Talkover
Mic priority
1U
Rack height
Features
3 mic/line inputs (Euroblock for mic, RCA for line) and 1 stereo line input on RCA
Main output on Euroblock, stereo or 2x mono; AUX/REC output on RCA
3-band tone control: 100 Hz, 2 kHz and 10 kHz, ±15 dB
Talkover assignable to each mic/line input
Talkover ducks the music by 30 dB when a microphone is used
+18V phantom power on microphone inputs; mic sensitivity adjustable on the rear panel
Mute input triggered by a dry contact (NO/NC), for fire alarm and safety systems
Passive cooling; external power supply included
Specifications
| Inputs | 3 mic/line (mic: 3-pin Euroblock; line: RCA), 1 stereo line (RCA) |
| Input sensitivity | Line: 0 dB; mic: -35 dB; adjust ±15 dB |
| Input impedance | Line: 50 kohm; mic: >1 kohm |
| Outputs | Main: 3-pin Euroblock, 600 ohm, stereo or 2x mono; AUX/REC: RCA, 10 kohm |
| Frequency response | Line: 10 Hz to 50 kHz; mic: 10 Hz to 30 kHz (-1 dB) |
| THD+N | Line: <0.005%; mic: <0.04% |
| Signal-to-noise ratio | Line: >100 dB; mic: >85 dB |
| Tone control | Bass 100 Hz, mid 2 kHz, treble 10 kHz, ±15 dB |
| Talkover | -30 dB, 2 seconds |
| Power | External ±17.5V DC supply (included), 100 to 240V AC; 4.5W |
| Dimensions (W x H x D) | 482.5 x 44 x 153.7 mm, 1U rack |
| Weight | 1.75 kg |
