Brass grounding ring for use during assembly of Elumen8 Showsafe 19-pin male Socapex connectors. Provides a common bonding point so all earth circuits in the multicore share a single ground reference. Most commonly used in cable assemblies built to North American practice, but equally useful where the assembler prefers a single bonded earth bar over individual pin terminations.
Features
✓
Solid brass for low resistance bonding
Solid brass for low resistance bonding
✓
For Elumen8 Showsafe male 19-pin Socapex connectors
For Elumen8 Showsafe male 19-pin Socapex connectors
✓
Allows all earth circuits to share a common ground
Allows all earth circuits to share a common ground
✓
Designed for solder termination during assembly
Designed for solder termination during assembly
✓
Common practice in North American cable builds
Common practice in North American cable builds
✓
Tidies the ground bus inside the connector shell
Tidies the ground bus inside the connector shell
Note
An assembly part for cable builders only. This is not a stand-alone connector or in-line accessory.
Specifications
| Brand | Elumen8 |
| Material | Brass |
| Application | 19-pin Showsafe male Socapex assembly |
| Termination | Solder |
| SKU | CONN417 |
