Biamp EX-S10 10" IP54 2-Way Coaxial Speaker with U-Bracket White £812.00 inc VAT
£676.67 ex VAT
Back to products
Biamp EX-S10SUB 10" IP54 Surface-Mount Sub with U-Bracket Black £770.00 inc VAT
£641.67 ex VAT
Biamp

Biamp EX-S10SUB 10" IP54 Surface-Mount Sub with ClickMount Pan-Tilt Bracket, Black

SKU: 920-01821-10000
Biamp EX-S10SUB 10″ IP54 Surface-Mount Sub with Tilt Bracket Black
Click to enlarge

    £770.00 inc VAT
    £641.67 ex VAT

    Ordered from supplier, allow 1–3 weeks
    FREE delivery by Mon 2nd NovOrder by 3pm tomorrow
    Click & Collect Fri 30th Oct ›Collect from our warehouse in Wembley, London
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    Other colours available
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Biamp EX-S10SUB (920-01821-10000) is a passive 10 inch surface-mount installation subwoofer in black with an IP54 rating for indoor or outdoor use, supplied with a ClickMount tilt bracket. It extends low frequency response in distributed systems and pairs with EX-S series full-range cabinets in venues, hospitality and exterior zones.

    Key Features
    10 inch (250 mm) treated paper LF cone
    Passive, low impedance operation
    Operating range 38 Hz to 140 Hz
    Selectable UXO 80 Hz or 125 Hz crossover presets
    IP54 rated to IEC 60529 for indoor or outdoor use
    Supplied with ClickMount tilt bracket
    Lever-actuated 4-position terminal block with pass-through
    Requires 35 Hz, 18 dB high-pass filter and DSP preset
    ETL listed to UL 1480A, CSA C22.2 62368-1
    Specifications
    Type 10-inch surface mount subwoofer
    Operating Mode Passive, low impedance
    Transducers LF 1 x 250 mm treated paper cone
    Power 300W continuous; 1200W peak
    Impedance 8Ω
    Frequency range 38 Hz to 140 Hz
    Sensitivity 89 dB (1W/1m)
    Maximum Output 112 dB; 118 dB peak; (UXO 80 Hz)
    Beamwidth Omnidirectional
    Recommended amplifier 300 W – 600 W, 8 Ω (49 V – 69 V)
    IP rating IP54 per IEC 60529; IEC 60068-2-5 (Solar Radiation); IEC 60068-2-11 (Salt Mist); IEC 60068-2-42 (SO2); IEC 60068-2-60 (Chlorine)
    Operating Environment Indoor/Outdoor
    Mounting ClickMount pan-tilt bracket or ClickMount U-Bracket
    Included Accessories CMX-LG [-B,-W] – Large ClickMount Pan-tilt Bracket Kit; EXUB-S10 [-B,-W] – EX-S10 ClickMount U-Bracket kit
    Material Grille:; Powder-coated perforated Marine Grade aluminium backed with hydrophobic cloth.; Enclosure:; High-impact UL94 5VB rated polycarbonate/ABS blend, painted UV resistant matte finish; Bracket: Heavily reinforced glass-filled nylon with UV-resistant painted matte finish cover
    Finish Black, RAL 9017
    Dimensions 529 x 309 x 439 mm (H x W x D)
    Weight 12.8 kg
    Certifications ETL listed to comply with UL 1480A; CSA STD C22.2# 62368-1
    Signal Processing Required Processing: 35 Hz, 18 dB high-pass filter; DSP preset
    Compare the Range
    Biamp EX-S10SUB 10″ IP54 Surface-Mount Sub with Tilt Bracket Black
    Biamp EX-S10SUB 10" IP54 Surface-Mount Sub with ClickMount Pan-Tilt Bracket, Black
    £770.00 inc VAT
    £641.67 ex VAT
    • Sensitivity: 89 dB (1 W, 8 ohm)
    • Power handling: 300 W (8 ohm nominal)
    • Recommended amplifier: 300 W to 600 W, 8 ohm
    • Dimensions (H x W x D): 529 x 310 x 312 mm
    • Weight: 12.8 kg
    Viewing Now
    Biamp EX-S10SUB 10″ IP54 Surface-Mount Sub with U-Bracket Black
    Biamp EX-S10SUB 10" IP54 Surface-Mount Sub with U-Bracket Black
    £770.00 inc VAT
    £641.67 ex VAT
    • Sensitivity: 89 dB (1 W, 8 ohm)
    • Power handling: 300 W (8 ohm nominal)
    • Recommended amplifier: 300 W to 600 W, 8 ohm
    • Dimensions (H x W x D): 529 x 310 x 312 mm
    • Weight: 12.8 kg
    View →

    Product Reviews

    No reviews yet — be the first to review this product.

    Bought this? It takes a minute.
    Review this product

    Reviews are checked by our team before they appear.

    More Information

    • Exceptional audio clarity with discreet styling
    • Easy to install with two mounting options
    • Utilizes innovative ClickMount pan-tilt for mounting
    • Low frequency boost for distributed applications
    • ETL listed to comply with UL 1480A, CSA 62368-1, CE marked, and RoHS complian
    • Finish: Black

    Manuals & Downloads

    PDFDatasheetPDF
    PDFA&E SpecificationsPDF
    PDFDrawing: EX-S10SUB-CMPDF
