The Ecler VEO-XRT44 is an HDBaseT receiver that turns a single CAT cable from a compatible HDBaseT transmitter back into HDMI, at up to 4K 60Hz 4:4:4 with HDR10. It includes a scaler that can upscale a 1080p source to a 4K output, plus Toslink audio breakout, IR and RS-232. It pairs with the VEO-XWT44E wall plate and VEO-MXH48T matrix in meeting rooms, lecture theatres and hospitality installs.
4K60 4:4:4
Max video
40 m
4K range
70 m
1080p range
HDCP 2.2
Copy protection
Receiver onlyThis is the receiving end. It needs an HDBaseT transmitter such as the VEO-XWT44E or an HDBaseT output on the VEO-MXH48T.
Cable and distance4K reaches 40 m and 1080p 70 m on CAT6a or CAT7. On CAT5e or CAT6 the limits are 35 m at 4K and 60 m at 1080p.
Features
HDBaseT receiver with an 18Gbps HDMI output
Video up to 4K at 60Hz 4:4:4, HDR10
Scaler upconverts a 1080p input to a 4K output
HDCP 2.2 and 1.4
Toslink audio breakout output and Toslink ARC input
Bidirectional IR and RS-232 over the link
Bidirectional 24V power over HDBaseT, so one power supply can sit at either end
EDID management with built-in settings or a custom EDID
Built-in 4K/1080p test pattern for fault finding
CEC pass-through, firmware updates over micro-USB
Specifications
| Video output | HDMI Type A, 18Gbps |
| Resolutions | 480i to 1080p at up to 60Hz, 1200p at up to 30Hz, 4K at up to 60Hz |
| Chroma subsampling | 4:4:4, 4:2:2, 4:2:0 |
| Colour depth | 8, 10, 12-bit (16-bit at 4K30 only) |
| HDCP | 2.2 / 1.4 |
| HDR | HDR10 |
| Transmission distance, CAT5e/6 | 4K: 35 m, 1080p: 60 m |
| Transmission distance, CAT6a/7 | 4K: 40 m, 1080p: 70 m |
| Audio connectors | Toslink breakout output, Toslink ARC input |
| Audio formats | PCM 2.0/5.1/7.1, Dolby Digital, DTS, Dolby TrueHD, DTS-HD Master Audio |
| Control ports | IR in, IR out, 3.5 mm minijack, RS-232 3-pin Euroblock, micro-USB firmware port |
| Power supply | 24V DC 1.25A adapter included |
| Power consumption | 12W maximum |
| Operating temperature | -5 to 55°C |
| Dimensions (W x H x D) | 140 x 20 x 84 mm |
| Weight | 290 g |
| Included | Mounting ears with screws, rubber feet, RS-232 cable (3-pin to DB9), 24V power adapter |
